Airtac 2LH Fluid Solenoid Valve 2LH03006C
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03006C Fluid Solenoid Valve Technical Details
- Model: 2LH03006C (L series low power consumption)
- Valve type: 2-position, 2-way normally closed
- Fluid medium: Compressed air (non-lubricated or lubricated)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Voltage tolerance: ±10% (DC models), ±15% (AC models)
- Voltage options:
- DC12V (2W), DC24V (2.2W)
- AC24V (3.5VA), AC110V (4VA), AC220V (4.5VA)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 280g ±5g (with coil)
- Dimensions: 52mm(W) × 54mm(H) × 56mm(D)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Ambient temperature: -5℃ to 80℃ (with intermittent 100℃ peak)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement required)
High-flow 2LH series solenoid valve featuring energy-efficient design (50% lower power consumption vs standard models). Optimized spool structure reduces pressure loss by 30% compared to conventional designs. The brass body with nickel plating ensures corrosion resistance in humid environments. Compatible with vacuum applications when paired with optional sealing kits.
- CNC machine tool coolant control systems
- Plastic injection molding machine pneumatics
- Beverage filling line actuator control
- Semiconductor wafer handling robotics
- Hydraulic system pilot stage control
Installation guidelines:1. Install downstream filter (5μm minimum)
2. Use anti-vibration mount in high-cycle applications (>5Hz)
3. For horizontal mounting, orient coil upward at ≥30° angle
4. Allow 15mm clearance for manual override operation
Not recommended for:- Oxidizing gases or combustible media
- Continuous duty cycles exceeding 90%
- Environments with ionic chemical exposure
| Property | Property Value |
|---|---|
| sku | 2LH03006C |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
