Airtac 2LH Fluid Solenoid Valve 2LH03006FI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03006FI Fluid Solenoid Valve Technical Details
- Model: 2LH03006FI
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Fluid compatibility: Air, water, light oils (ISO VG32 or thinner)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow rate: 120 L/min (Cv=0.21 at 0.5 MPa)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 310g ±5% (including coil)
- Dimensions: 75mm(L) × 54mm(W) × 35mm(H)
- Seal material: FKM (Viton® equivalent) for high chemical resistance
- Valve body: Anodized aluminum alloy with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.8W (DC), 3.5VA (AC)
- Protection rating: IP67 (dustproof and temporary immersion resistant)
- Service life: ≥10 million cycles (under rated conditions)
High-flow compact solenoid valve featuring corrosion-resistant construction and dual-port exhaust design. The direct-acting mechanism ensures reliable operation in low-pressure systems (≥0.1MPa). Optimized flow path geometry reduces pressure drop by 18% compared to previous generation models. Compatible with pneumatic and hydraulic systems using non-viscous fluids.
- Industrial cleaning equipment fluid control
- Beverage dispensing machine liquid pathways
- CNC machine tool coolant management
- Automated irrigation systems
- Laboratory analytical instrument flow switching
- Semiconductor wafer processing equipment
Installation guidelines:
Mount in any orientation except coil-down position. Install a 10μm filter upstream.
For liquid applications, ensure full priming to prevent cavitation. Allow 15mm
clearance around coil for heat dissipation. Use thread sealant on male ports only.
| Property | Property Value |
|---|---|
| sku | 2LH03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
