Airtac 2S Fluid Control Valve 2S05010AI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05010AI Fluid Control Valve Technical Specifications
- Model: 2S05010AI
- Type: 5-port/2-position (dual solenoid)
- Port configuration: 2 exhaust ports, 2 outlet ports, 1 supply port
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa
- Max flow capacity: 750 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 215g ±5g
- Dimensions: 58mm(L) × 43mm(W) × 50mm(H)
- Body material: Anodized aluminum alloy (ADC12)
- Seal material: Heat-resistant NBR (nitrile butadiene rubber)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤25ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Cycle life: ≥10 million operations
High-flow directional control valve with dual solenoid activation, featuring a robust anodized aluminum body and pre-lubricated seals for maintenance-free operation. The optimized flow path design reduces pressure drop by 15% compared to previous generations. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality standard.
- Automated assembly line cylinder sequencing
- Plastic injection molding machine clamp control
- CNC tool changer positioning systems
- Beverage filling station pneumatic actuators
- Lithium battery production vacuum handling
Installation guidelines:
Mount with M4 screws (recommended torque 1.2N·m). Maintain horizontal orientation for optimal drainage.
Install silencers on exhaust ports in food-grade environments. Allow 15mm clearance around coil for heat dissipation.
Critical note:
Do not apply surge voltage exceeding 130% of rated voltage.
Use surge absorbers when controlling with PLC outputs.
Lubricate pivot points every 5,000 operating hours in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 2S05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
