Airtac 2S Fluid Control Valve 2S05010B
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S Series Fluid Control Valve 2S05010B Technical Details
- Model Number: 2S05010B
- Valve Type: 5-port, 2-position directional control (monostable)
- Port Configuration: P (pressure), A/B (actuator ports), R/S (exhaust)
- Port Thread Size: PT1/8 (BSPP) with metal sealing
- Operating Pressure Range: 0.2–1.0 MPa (29–145 psi)
- Maximum Flow Rate: 750 L/min (Cv=1.2)
- Voltage Options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil Insulation Class: Class F (155℃)
- Response Time: ≤15ms (excitation), ≤20ms (reset)
- Ambient Temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Seal Material: Heat-resistant NBR (Nitrile Rubber)
- Body Material: Aluminum alloy with hard anodizing
- Weight: 215g ±5g (excluding connector)
- Dimensions: 50mm(L) × 34mm(W) × 67mm(H) (manual override protrusion excluded)
- Protection Rating: IP67 (coil), IP40 (valve body)
- Service Life: ≥10 million cycles (under rated conditions)
High-flow proportional control valve with manual override capability, featuring optimized flow paths for reduced pressure drop. The hardened aluminum body withstands vibration in mobile applications. Requires 5μm filtration (40μm for emergency use) and lubricated air (ISO VG32 equivalent). Compatible with vacuum applications when paired with EPDM seals.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery air circuit distribution
- Semiconductor wafer handling vacuum/pressure systems
- Food processing pneumatic actuators (oil-free version available)
Installation guidelines:
Mount with M4 screws (max torque 1.2N·m). Maintain ≥15mm clearance
around exhaust ports. For horizontal mounting, orient coil upward
to prevent debris accumulation. Use shock absorbers in high-vibration environments.
Critical note:
Not compatible with phosphate ester-based lubricants.
Always install downstream of quick exhaust valves.
Cycle rate limited to 5Hz for DC models, 3Hz for AC variants.
| Property | Property Value |
|---|---|
| sku | 2S05010B |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
