Airtac 2S Fluid Control Valve 2S05010BI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05010BI 2-Way Fluid Control Valve Specifications
- Model: 2S05010BI
- Type: 2-position 5-port single solenoid (pilot-operated)
- Port configuration: 5/2-way
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.2–0.8 MPa
- Maximum flow rate: 850 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Power consumption: 1.8W (DC), 5VA (AC)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤20ms (at rated voltage)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 650g ±5%
- Dimensions: 54mm(L) × 45mm(W) × 50mm(H)
- Mounting type: Sub-base compatible (ISO 5599-1)
- Cycle rate: ≥5 million cycles (at 1Hz frequency)
High-flow directional control valve with low power consumption design, featuring aluminum alloy body with hard anodized surface treatment for enhanced corrosion resistance. The dual-pressure sealed spool structure ensures reliable switching even under pressure fluctuations. Requires 5μm filtered compressed air with lubricator (ISO 8573-1 class 4).
- High-cycle automation equipment (e.g., bottle capping machines)
- Plastic injection molding machine cylinder control
- Pneumatic conveyor systems with rapid actuation
- Automotive assembly line tooling controls
- Food processing pneumatic circuits (oil-mist free operation)
Installation guidelines:
Maintain horizontal mounting position for optimal drainage.
Use shock-absorbing brackets in high-vibration environments.
Allow 15mm clearance above valve for coil replacement.
Perform monthly manual override testing for maintenance.
- Minimum holding pressure: 0.15 MPa
- Max allowable backpressure: 10% of inlet pressure
- Coil insulation class: Class F (155℃)
- Pressure drop at max flow: ≤0.12 MPa
| Property | Property Value |
|---|---|
| sku | 2S05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
