Airtac 2S Fluid Control Valve 2S05010EI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S Series Fluid Control Valve 2S05010EI Technical Details
- Model: 2S05010EI
- Type: 5-port, 2-position directional control valve (pneumatic)
- Port configuration: 1/4" NPT (G1/8 optional)
- Operating pressure range: 0.2–1.0 MPa
- Max flow rate: 850 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5g
- Dimensions: 76mm(L) × 32mm(W) × 65mm(H)
- Seal material: Heat-resistant HNBR (Hydrogenated Nitrile)
- Ambient temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection class: IP67 (dustproof & temporary immersion)
- Port thread depth: 10mm (minimum engagement)
High-flow solenoid valve with reinforced aluminum alloy body and dual-coil heat dissipation design. Optimized spool structure reduces pressure drop by 18% compared to previous generation. Features manual override button for emergency operation and status indicator LED (DC models only). Compatible with ISO 15407-1 standards.
- Industrial automation sequencing systems
- Pneumatic cylinder reciprocation control
- Packaging machinery clamp actuators
- Automotive assembly line tooling
- Food processing air knife systems
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance below valve for manifold heat dissipation.
Use 5μm filtration (40μm for emergency bypass). Lubricated air requires oil mist separator.
Voltage compatibility:
Ensure supply voltage matches coil specification within ±10% tolerance.
AC/DC variants have different terminal configurations - verify polarity for DC models.
| Property | Property Value |
|---|---|
| sku | 2S05010EI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC24V |
