Airtac 2S Fluid Control Valve 2S05015BI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05015BI Fluid Control Valve Specifications
- Model: 2S05015BI
- Type: 5-port 3-position closed center (Double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC24V (±10%), AC220V (50/60Hz)
- Max flow rate: 1000 L/min (ANR)
- Response time: ≤20ms (at 0.5MPa)
- Weight: 320g ±5%
- Dimensions: 50mm(L) × 40mm(W) × 82mm(H)
- Valve body material: Aluminum alloy (anodized)
- Seal material: FKM fluorocarbon (standard) / NBR optional
- Temperature range: -5℃ to 60℃ (with FKM seals)
- Power consumption: 2.2W (DC24V) / 3.5VA (AC220V)
- Protection rating: IP67 (coil) / IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with closed-center functionality, featuring dual manual override and position indicator. The optimized spool design achieves 30% lower pressure drop compared to previous generation models. Requires 5μm filtered air with oil mist lubrication (ISO 8573-1 Class 3.4.2). Compatible with ISO 15407-1 mounting interfaces.
- Industrial robotic arm end-effector control
- Food processing pneumatic circuits (sanitary design variant available)
- Pharmaceutical batch reactor pressure sequencing
- Automated packaging line clamp positioning
- Semiconductor wafer handling vacuum/pressure systems
Installation note:
Mount in vibration-free environment using M5 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance below valve for manifold heat dissipation.
Perform initial 500-cycle dry run before full-pressure operation.
| Property | Property Value |
|---|---|
| sku | 2S05015BI |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
