Airtac 2S Fluid Control Valve 2S05015EI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05015EI Fluid Control Valve Specifications
- Model: 2S05015EI
- Type: 5-port 3-position closed center (electro-pneumatic)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.6W (standard), 2.2W (high power option)
- Weight: 680g ±5% (including coil)
- Dimensions: 60mm(L) × 45mm(W) × 85mm(H)
- Body material: Anodized aluminum alloy (ISO-AlSi10Mg)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (with dry air)
- Flow capacity: 850 l/min (Cv=1.5 at 0.5MPa)
- Response time: ≤15ms (exhaust to center position)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with closed-center configuration, featuring dual solenoid operation and precision-machined spool. The hardened stainless steel guide sleeves ensure ≤0.05mm internal leakage at 0.6MPa. Compatible with ISO 15407-1 standards, requires 5μm filtered compressed air with oil mist (ISO 8573-1 Class 3.4.2).
- Pneumatic cylinder sequencing in assembly lines
- Vacuum cup control systems for material handling
- Dual-pressure regulation in injection molding machines
- Precision air brake systems for automated guided vehicles
- Cleanroom-compatible automation (low particle emission)
Installation note:
Mount with vibration-damping brackets in high-cycle applications (>5Hz).
Maintain ≥30mm clearance below valve for exhaust heat dissipation.
Use M5x0.8 mounting screws with 4.5-5.5N·m torque specification.
| Property | Property Value |
|---|---|
| sku | 2S05015EI |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC24V |
