Airtac 2S Fluid Control Valve 2S15015B
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S15015B Fluid Control Valve Technical Specifications
- Model: 2S15015B
- Type: 5-port 2-position (5/2-way) solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.8
- Max flow rate: 850 L/min (ANR)
- Weight: 0.82 kg ±3%
- Dimensions: 80mm(L) × 50mm(W) × 65mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤20ms (at rated voltage)
- Protection class: IP67 (dustproof/water immersion resistant)
- Port thread depth: 12mm (minimum engagement)
- Compatible fluids: Air, inert gases (N₂ required for oxygen systems)
High-flow directional control valve featuring dual-coil surge protection and manual override capability. The hardened aluminum alloy body with electroless nickel plating ensures corrosion resistance in humid environments. Designed for systems requiring rapid cycling (up to 5Hz) with integrated LED position indicator for status monitoring.
- Automated packaging line actuators
- CNC machine tool clamping systems
- Beverage filling station pneumatic controls
- Lithium battery production equipment
- Automotive welding robot end-effectors
Installation protocol:
Install with 10-15mm vibration dampening gap around valve. Use 40μm filter + 5μm lubricator (ISO 8573-1:2010 Class 4.4.2) upstream. For vertical mounting, position coils above valve body to prevent debris accumulation. Perform monthly manual cycling during maintenance shutdowns.
| Property | Property Value |
|---|---|
| sku | 2S15015B |
| Port Size | PT 1/2 |
| Flow Aperture | <15mm> |
| Coil Voltage | DC24V |
