Airtac 2SH High Pressure Solenoid Valve 2SH03006FI
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH Series High-Pressure Solenoid Valve 2SH03006FI Technical Details
- Model: 2SH03006FI
- Type: 3-position, 5-way (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.05–25 MPa (73-3626 psi)
- Max pressure capacity: 31.5 MPa (4568 psi burst pressure)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 520g ±3% (with coil)
- Dimensions: 78mm(L) × 42mm(W) × 92mm(H)
- Body material: Anodized aluminum alloy (ISO-AlSi10Mg)
- Seal materials: HNBR + Fluororubber (FKM) composite
- Temperature range: -40℃ to 120℃ (with dry air)
- Flow capacity: 1800 Nl/min (Cv=1.8 at 0.7MPa)
- Response time: ≤15ms (at 20℃ nominal pressure)
- Protection rating: IP67 (dust/water ingress protection)
- CE/RoHS compliant: Yes
High-performance hydraulic/pneumatic valve engineered for extreme pressure systems. Features redundant sealing technology with anti-vibration coil design and pressure-balancing spool structure. Includes manual override and position indicator. Requires ISO 8573-1:2010 Class 3-4-3 compressed air (max 50mg/m³ oil content).
- Hydraulic pressurization systems in die casting machines
- High-pressure gas control for leak testing equipment
- Automotive brake system simulation rigs
- Subsea equipment pressure balancing systems
- CNC machine tool clamping mechanisms
Installation protocol:
Mount using M5x12mm stainless steel screws (max torque 3.5Nm).
Maintain 20mm clearance from adjacent components for heat dissipation.
Perform 500-hour maintenance cycles with ISO VG32 hydraulic oil lubrication.
| Property | Property Value |
|---|---|
| sku | 2SH03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
