Airtac 2SH High Pressure Solenoid Valve 2SH05010EI
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05010EI High-Pressure Solenoid Valve Technical Details
- Model: 2SH05010EI
- Type: 2-position, 5-port direct-acting (high-pressure variant)
- Port configuration: 1/4" NPT (G1/8 optional)
- Operating pressure range: 0.5–25 MPa (72.5–3,625 PSI)
- Max pressure surge: 31.5 MPa (burst pressure 63 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 420g ±5% (including coil)
- Dimensions: 78mm(L) × 42mm(W) × 64mm(H)
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: Fluororubber (FKM) standard (HNBR optional)
- Temperature range: -20℃ to 150℃ (media dependent)
- Flow coefficient (Cv): 1.8 (at 7 bar)
- Response time: ≤15ms (at rated voltage)
- Electrical connection: DIN43650 Form A (direct wiring terminal optional)
- Protection rating: IP67 (dust/water resistant)
- Certification: CE, RoHS, REACH compliant
Industrial-grade high-pressure solenoid valve engineered for extreme hydraulic and pneumatic systems. Features dual-chamber sealing technology with pressure-balancing structure for stable operation under fluctuating loads. The hardened stainless steel plunger and military-grade epoxy-coated coil ensure 500,000+ cycle durability. Compatible with air, water-glycol mixtures, and light hydraulic oils (ISO VG 32-68).
- Hydraulic pressurization systems in die-casting machines
- High-pressure coolant control in CNC machining centers
- Automotive brake system testing rigs
- Offshore oil & gas blowout preventer controls
- Plastic injection molding machine hydraulic circuits
Installation protocol:
Always install with pressure direction arrow alignment. Requires pre-filtering to 10μm absolute.
For vertical mounting (preferred orientation), allow 30-minute run-in period at 50% pressure.
Annual maintenance: Replace desiccant in air prep units and inspect pilot orifices for erosion.
- Zero-pressure start capability (minimum 0.3MPa for full flow)
- Built-in manual override for system debugging
- EMC protection: 4kV surge immunity (EN 61000-4-5)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
| Property | Property Value |
|---|---|
| sku | 2SH05010EI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
