Airtac 2SL Fluid Control Valve 2SL03006A
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL03006A Fluid Control Valve Technical Details
- Model: 2SL03006A
- Type: 3-position, 5-way closed center (double solenoid)
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.8 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤20ms (energize), ≤15ms (de-energize)
- Flow capacity: 850 l/min (ANR)
- Seal material: Heat-resistant NBR (nitrile butadiene rubber)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Weight: 210g ±5g (excluding accessories)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Protection standard: IP67 (dustproof & waterproof)
- Manual override: Built-in emergency switch
High-flow proportional control valve with dual coil redundancy, featuring gold-plated connectors for enhanced corrosion resistance. Optimized for precision flow modulation in closed-loop systems, with shock-resistant construction for industrial vibration environments. Requires ISO 8573-1:2010 Class 3.4.2 compressed air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with position feedback
- Food processing pneumatic circuits (NSF-H1 grease compatible)
- Semiconductor wafer handling robotics
Installation protocol:
Mount on vibration-damping brackets using M5 mounting screws (included).
Maintain 15° maximum angular deviation from vertical axis.
Purge air lines for 30 seconds before initial operation.
| Property | Property Value |
|---|---|
| sku | 2SL03006A |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
