Airtac 2SL Fluid Control Valve 2SL03006CI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL03006CI Fluid Control Valve Technical Details
- Model: 2SL03006CI
- Type: 3-position, 5-way closed center (pneumatic pilot operated)
- Port configuration: 5/3-way
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow capacity: 1,200 Nl/min
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.8W (DC24V)
- Response time: ≤30ms (actuation/deactuation)
- Weight: 320g ±5%
- Dimensions: 98mm(L) × 52mm(W) × 76mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with center-block function, featuring triple-position memory control for precision mid-stroke positioning. Equipped with manual override and surge suppression for shock-free operation. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.2 purity standards.
- Plastic injection molding machine clamp control
- Automated assembly line positioning systems
- Paper converting equipment cylinder sequencing
- Die-casting machine safety interlocks
- Semiconductor wafer handling robotics
Maintenance protocol:
Lubricate pilot piston every 500,000 cycles using ISO VG32 turbine oil.
Avoid parallel mounting with heat sources exceeding 55℃ ambient temperature.
- Port A/B exhaust options: Independent (S), Common (C), or Exhaust regulation (R)
- Optional position sensors: Magnetic proximity (PNP/NPN) or mechanical limit switches
- Mounting variants: Panel, sub-base, or manifold block installation
| Property | Property Value |
|---|---|
| sku | 2SL03006CI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
