Airtac 2SL Fluid Control Valve 2SL03006EI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL Series Fluid Control Valve 2SL03006EI Technical Details
- Model: 2SL03006EI
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 850 L/min (ANR)
- Response time: ≤30ms (exhaust to center)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 60mm(L) × 48mm(W) × 98mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -10℃ to 80℃ (with anti-freeze measures below 0℃)
- Power consumption: 4.5W (AC), 3.6W (DC)
- Port thread depth: 10mm (minimum engagement)
- Protection rating: IP67 (dustproof & temporary immersion)
- Service life: ≥10 million cycles (under rated conditions)
High-flow directional control valve with center-block function, featuring dual manual overrides and LED status indicators. The hardened aluminum alloy body withstands hydraulic shock up to 1.5MPa transient pressure. Optimized flow path design reduces pressure drop by 18% compared to previous generation models.
- Pneumatic clamping systems in CNC machining centers
- Automatic sorting line diverters
- Plastic injection molding machine actuators
- Bottle filling/palletizing equipment
- Test bench pressure sequencing systems
Installation guidelines:
Use M5 mounting screws with 0.6-0.8Nm torque. Maintain 15° maximum
angular deviation from vertical axis. Install downstream filters
(5μm or finer) when used with air cylinders requiring ISO 8573-1
Class 3 air quality.
| Property | Property Value |
|---|---|
| sku | 2SL03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
