Airtac 2SL Fluid Control Valve 2SL03006FI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL03006FI Fluid Control Valve Technical Specifications
- Model: 2SL03006FI
- Type: 3-position, 5-way closed center (Double solenoid)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.1–0.8 MPa
- Max flow capacity: 750 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 320g ±5% (including coil)
- Dimensions: 56mm(L) × 40mm(W) × 82mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 3.5W (DC), 4.2VA (AC)
- Response time: ≤30ms (exhaust to center position)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
High-flow proportional control valve with center exhaust function, featuring aluminum alloy body with hard anodized finish for corrosion resistance. The dual solenoid configuration enables precise mid-position control in pneumatic circuits. Integrated surge suppression protects against voltage spikes. Requires 5μm filtered compressed air with oil mist (ISO 8573-1:2010 Class 4.4.3).
- Multi-position cylinder control in automated assembly lines
- Pneumatic clamping systems with safety interlocks
- Textile machinery tension control mechanisms
- Plastic injection molding machine ejectors
- Automotive testing equipment position hold systems
Installation guidelines:
Mount horizontally with arrow direction matching airflow. Use flexible tubing
for the first 300mm of connections to reduce vibration transfer. Minimum
15mm clearance required above valve for heat dissipation. Lubricate seals
with ISO VG32 turbine oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 2SL03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
