Airtac 2SL Fluid Control Valve 2SL03008AI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL03008AI Fluid Control Valve Technical Specifications
- Model: 2SL03008AI
- Type: 3-position 5-way (double solenoid, center exhaust)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.2–0.8 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (including coil)
- Dimensions: 58mm(L) × 34mm(W) × 72mm(H) (body only)
- Flow capacity: 850 l/min (ANR)
- Seal materials: HNBR (hydrogenated nitrile) with PPS piston
- Temperature tolerance: -10℃ to 70℃ (non-freezing)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤25ms (excitation), ≤35ms (reset)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with dual coil redundancy, featuring a dust-resistant plunger mechanism and copper-free aluminum alloy construction. Optimized for rapid cycling (≥5 million operations) in high-vibration environments. Requires 5-7μm filtration with oil mist lubrication (ISO VG32 recommended).
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery shuttle control systems
- Bottle cap sorting/rejection mechanisms
- Automated welding positioners
- Lithium battery formation equipment
Installation guidelines:
Mount with M5 screws (2.0N·m torque max). Maintain 15mm clearance
below valve for exhaust dispersion. Use anti-vibration washers in
mobile applications. Lubricate pilot ports quarterly in high-cycle systems.
Critical note:
Avoid continuous energizing >30 minutes. For vertical mounting,
position coil upward to prevent particulate accumulation.
| Property | Property Value |
|---|---|
| sku | 2SL03008AI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
