Airtac 2SL Fluid Control Valve 2SL03008B
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL Series Fluid Control Valve 2SL03008B Technical Details
- Model: 2SL03008B
- Valve type: 5-port 2-position (5/2-way) solenoid operated
- Port thread: G1/4 (ISO228 standard)
- Effective area: 18mm² (pilot piston design)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (exhaust to actuation)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -5℃ to 80℃ (with condensation prevention)
- Protection class: IP67 (dust-tight, protected against temporary immersion)
- Weight: 295g ±5g (including coil)
- Dimensions: 60mm(L) × 35mm(W) × 50mm(H) (excluding fittings)
- Port alignment: ISO 5599-1 standard (modular mounting compatible)
- Flow capacity: 650 l/min (Cv=1.2 at 0.5MPa)
High-flow directional control valve with dual-pressure operation capability, featuring a low-friction spool design for reduced hysteresis. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Includes manual override button for system debugging and emergency operation.
- Pneumatic clamping systems in CNC machining centers
- Automated production line cylinder sequencing
- Plastic injection molding machine ejectors
- Food processing pneumatic circuits (oil-free version available)
- Automotive tire assembly equipment
Installation guidelines:
Mount horizontally with manifold brackets (max 0.5mm misalignment tolerance).
Use 5μm filtration with automatic drain. Lubrication requires ISO VG32 turbine oil
if operating below -10℃. Maintain 0.3m minimum clearance from high-frequency inverters.
| Property | Property Value |
|---|---|
| sku | 2SL03008B |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
