Airtac 2SL Fluid Control Valve 2SL03008BI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL Series Fluid Control Valve 2SL03008BI Technical Details
- Model: 2SL03008BI
- Valve type: 5-port 2-position (5/2-way) solenoid valve
- Port thread size: 1/4" BSPP (G1/4)
- Operation mode: Double solenoid with spring return
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 L/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE piston ring
- Ambient temperature: -10℃ to 80℃ (14℉ to 176℉)
- Weight: 500g ±5% (with coil)
- Dimensions: 56mm(W) × 46mm(H) × 128mm(L)
- Electrical protection: Class F insulation (155℃)
- Protection rating: IP67 (coil), IP40 (valve body)
- Expected service life: ≥10 million cycles (at rated conditions)
High-flow proportional control valve featuring dual-coil redundant operation and dust-resistant spool design. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Includes manual override button for system debugging and emergency control. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Automated production line cylinder sequencing
- Plastic injection molding machine clamp control
- CNC rotary table positioning systems
- Automotive welding robot end effectors
- Food processing pneumatic actuators (oil-free version available)
Installation guidelines:
Mount valve within 10 meters of actuators using reinforced nylon tubing.
Maintain 20mm clearance above valve for heat dissipation. Lubricate air supply
with ISO VG32 turbine oil if cycle rate exceeds 5Hz. Perform monthly
function tests in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | 2SL03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
