Airtac 2SL Fluid Control Valve 2SL03008CI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL03008CI Fluid Control Valve Technical Details
- Model: 2SL03008CI
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: G1/8 (ISO standard)
- Operating pressure: 0.1–1.0 MPa
- Max flow rate: 1000 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.68 kg ±5%
- Dimensions: 56mm(W) × 56mm(H) × 140mm(L)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤25ms (exhaust to actuation)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤10% of rated voltage
High-flow directional control valve with dual coil redundancy, featuring anti-vibration terminals and surge protection circuitry. The aluminum alloy body with hard anodized finish resists chemical corrosion in harsh environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Plastic injection molding machine clamp systems
- Automated assembly line cylinder sequencing
- Textile machinery tension control
- Semiconductor wafer handling robots
- Hydraulic system pilot stage control
Installation guidelines:
Mount on flat surface using M5 mounting screws (not included).
Maintain 20mm clearance below valve for tubing access.
Lubricate seals with ISO VG32 turbine oil before initial use.
Critical note:
Do NOT use silicone-based lubricants.
Cycle test at 50% duty cycle for first 500 operations.
Minimum holding time: 0.3 seconds for stable switching.
| Property | Property Value |
|---|---|
| sku | 2SL03008CI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
