Airtac 2SL Fluid Control Valve 2SL03008EI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL03008EI 2-Way Fluid Control Valve Technical Details
- Model: 2SL03008EI
- Type: 2-position 5-port direct-acting solenoid valve
- Port configuration: 1/4" BSPP (G1/4)
- Operation mode: Normally closed (NC) / Optional normally open (NO)
- Pressure range: 0.15-0.8 MPa (21.7-116 PSI)
- Flow capacity: 850 L/min (Cv=1.2)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Body material: Aluminum alloy (anodized finish)
- Seal material: Heat-resistant NBR (Nitrile) up to 80℃
- Ambient temperature: -5℃ to 80℃ (no freeze)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Protection class: IP67 (dust/water resistant)
- Weight: 480g ±5% (without connector)
- Dimensions: 56mm (W) × 56mm (H) × 108mm (L)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with zero-pressure start capability, featuring brass internal flow paths for reduced corrosion. The dual-coil latching design maintains position during power loss. Includes manual override button for system debugging. Requires 5μm filtration (lubricated or non-lubricated air).
- Plastic injection molding machine clamp control
- Automated production line cylinder sequencing
- Textile machinery tension regulation systems
- Semiconductor wafer handling robotics
- Hydraulic system pilot stage control
Installation guidelines:
Mount with vibration-damping gaskets in high-shock environments.
Maintain 20mm clearance below valve for connector access.
Use PTFE tape on threads with clockwise wrapping direction.
Critical note:
Avoid continuous duty cycles exceeding 90% -
For 100% ED operation, specify 2SL03008EI-HD variant.
| Property | Property Value |
|---|---|
| sku | 2SL03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
