Airtac 2SL Fluid Control Valve 2SL05010BI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL05010BI Fluid Control Valve Technical Details
- Model: 2SL05010BI
- Type: 2-position, 5-port directional control valve (bi-stable)
- Port configuration: 5/2-way (double solenoid)
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure range: 0.2–1.0 MPa
- Maximum flow rate: 750 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤50ms (actuation/deactivation)
- Seal material: Fluorinated rubber (FKM) for chemical resistance
- Temperature tolerance: -10℃ to 80℃ (non-freezing)
- Protection class: IP67 (dust/water resistant)
- Weight: 280g ±5g (with connectors)
- Dimensions: 56mm(W) × 56mm(H) × 102mm(L)
- Mounting: ISO 5599-1 standard interface
- Cycle life: ≥10 million operations
High-flow proportional control valve with dual electromagnetic coils for precise directional switching. Features corrosion-resistant aluminum alloy body with hardened brass cores. Requires 5μm filtration (lubricated air recommended). Includes manual override and position indicator window for maintenance diagnostics.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with rapid cylinder reversal
- Wastewater treatment plant pneumatic gates
- Food-grade air systems (FDA-compliant seals optional)
Installation protocol:
Maintain horizontal mounting orientation (±15° tolerance). Use anti-vibration
brackets in high-cycle applications (>5Hz). Allow 30mm clearance on exhaust ports
for muffler attachment. Perform weekly manual cycling during standby periods.
| Property | Property Value |
|---|---|
| sku | 2SL05010BI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | DC24V |
