Airtac 2ST Fluid Control Valve 2ST03006CI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03006CI Fluid Control Valve Technical Details
- Model: 2ST03006CI
- Type: 5/2-way pilot-operated solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.15-0.8 MPa (21.7-116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Flow capacity: 1200 NL/min (Cv=1.8 at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Protection rating: IP65 (coil)/IP40 (valve body)
- Weight: 400g ±5% (including coil)
- Dimensions: 65mm(L) × 40mm(W) × 90mm(H)
- Port thread depth: 12mm (minimum engagement)
- Expected service life: 10 million cycles (under rated conditions)
High-flow directional control valve with dual solenoid operation, engineered for precision bi-directional actuator control. Features a copper-free aluminum alloy body with anodized surfaces for corrosion resistance. The optimized spool structure ensures ≤0.5ms differential in simultaneous coil activation scenarios. Requires 5μm filtered air with oil mist lubrication (ISO VG32 recommended).
- Automated production line cylinder sequencing
- Plastic injection molding machine clamp control
- Material handling system diverters
- Automotive assembly robotics
- Semiconductor wafer handling equipment
- Textile machinery tension control systems
Installation protocol:
Mount in vibration-free environment using M5 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance below valve for manifold heat dissipation.
Always install downstream moisture separator with auto-drain.
| Property | Property Value |
|---|---|
| sku | 2ST03006CI |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC 110V |
