Airtac 2ST Fluid Control Valve 2ST03006F
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03006F Fluid Control Valve Specifications
- Model: 2ST03006F
- Type: 3-position, 5-way closed center (Pilot-operated)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.2–0.8 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (ANR)
- Response time: ≤30ms (at 0.5MPa)
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 40mm(W) × 35mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: ≤2.5W (DC), ≤4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
- Max switching frequency: 5Hz (with pilot assist)
High-flow directional control valve with central exhaust design, featuring dual-pressure operation capability. The hardened aluminum body with anti-vibration mounting points ensures stable performance in dynamic environments. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (40μm filtration recommended).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Food processing pneumatic circuits (oil-free version available)
- Battery production vacuum/pressure switching
- Textile machinery tension control
Installation note:
Maintain 15° maximum angular tolerance during mounting. Use copper-free
lubrication if required. For continuous operation, install thermal relief
valves when ambient temperature exceeds 50℃. Manual override requires
3mm hex key (included in industrial package).
| Property | Property Value |
|---|---|
| sku | 2ST03006F |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC12V |
