Airtac 2ST Fluid Control Valve 2ST03006FI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03006FI Fluid Control Valve Technical Specifications
- Model: 2ST03006FI
- Type: 2-position, 3-way (normally closed)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5g
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Flow capacity: 750 L/min (ANR)
- Seal material: HNBR (Hydrogenated Nitrile) for high oil resistance
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 2.8W (DC24V), 4.5VA (AC220V)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with precision feedback mechanism, featuring brass body construction with electroless nickel plating. Designed for precise fluid regulation in demanding industrial environments. Requires 5μm filtration (recommended ISO 8573-1:2010 Class 3.4.2 air quality). Includes manual override function for emergency operation.
- CNC machine tool coolant control systems
- Semiconductor manufacturing gas flow regulation
- Automated paint spraying equipment
- Hydraulic system pilot stage control
- Food processing pneumatic actuators
- Battery production line vacuum systems
Installation guidelines:
Mount horizontally with arrow direction matching flow. Use vibration-damping
brackets in high-frequency environments. Perform lubrication maintenance every
500,000 cycles using ISO VG32 turbine oil. Avoid rapid pressure fluctuations
exceeding 0.1 MPa/sec.
| Property | Property Value |
|---|---|
| sku | 2ST03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC12V |
