Airtac 2ST Fluid Control Valve 2ST03008C
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008C Fluid Control Valve Specifications
- Model: 2ST03008C
- Type: 3-position, 5-way (double solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.15–0.9 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Flow capacity: 1,200 NL/min (ANR)
- Response time: ≤25 ms (exhaust to actuation)
- Seal material: HNBR (Hydrogenated Nitrile) with wear-resistant coating
- Temperature range: -10℃ to 70℃ (with anti-freeze measures below 0℃)
- Weight: 480g ±5% (excluding accessories)
- Dimensions: 60mm(L) × 45mm(W) × 85mm(H) (manifold mounting surface)
- Port thread depth: 12mm (minimum engagement 9mm)
- Protection rating: IP67 (dustproof & temporary immersion resistant)
- Service life: ≥10 million cycles (under rated conditions)
High-flow directional control valve with dual electromagnetic control, featuring optimized spool geometry for reduced pressure drop. The hardened stainless steel guide structure ensures precise position holding in industrial vibration environments. Compatible with ISO 15407-1 standard subplates.
- Automated assembly line cylinder sequencing
- Plastic injection molding machine clamp control
- CNC tool changer positioning systems
- Food processing pneumatic actuators (oil-free version available)
- Battery manufacturing pressurization circuits
Installation note:
Use M5 mounting screws with 0.6-0.8Nm torque. For vertical installation,
position solenoid coils horizontally to prevent debris accumulation.
Always install downstream filters (≤25μm) when used with lubricated air systems.
| Property | Property Value |
|---|---|
| sku | 2ST03008C |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC 110V |
