Airtac 2ST Fluid Control Valve 2ST03008CI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008CI Fluid Control Valve Technical Details
- Model: 2ST03008CI
- Type: 3-position, 5-way closed center (pneumatic pilot operation)
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 1,200 NL/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil protection: Built-in surge suppressor
- Weight: 480g ±5% (including accessories)
- Dimensions: 55mm(L) × 42mm(W) × 72mm(H)
- Body material: Anodized aluminum alloy (ISO-AlSi10Mg)
- Seal material: HNBR (Hydrogenated Nitrile) for chemical resistance
- Temperature range: -10℃ to 80℃ (no ice formation)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (dust/water immersion protection)
- Mounting style: ISO 5599/1 compliant sub-base
High-flow directional control valve with triple-position memory function, featuring dual electromagnetic pilot operation for precise mid-position control. The enhanced HNBR seals enable compatibility with synthetic lubricants and mild chemicals. Optimized flow path geometry reduces pressure drop by 18% compared to previous generation models.
- Clamping sequence control in CNC machining centers
- Pneumatic cylinder synchronization systems
- Automated material handling equipment
- Plastic injection molding machine ejectors
- Test bench pressure regulation systems
Installation guidelines:
Maintain 0.5-1.0mm alignment tolerance during sub-base mounting.
Use copper-free lubricants only. Pre-charge pilot circuit for 2 seconds
before initial operation. Requires minimum 5μm filtration.
| Property | Property Value |
|---|---|
| sku | 2ST03008CI |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC 110V |
