Airtac 2ST Fluid Control Valve 2ST03008FI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008FI Fluid Control Valve Technical Specifications
- Model: 2ST03008FI
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Max flow rate: 850 NL/min (ANR)
- Response time: ≤15ms (exhaust to pilot)
- Seal material: FKM/Viton (standard), EPDM optional
- Temperature range: -10℃ to 70℃ (14°F to 158°F)
- Weight: 0.52 kg (1.15 lbs)
- Dimensions: 64mm(L) × 42mm(W) × 90mm(H)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
- Flow capacity (Cv): 1.8
High-precision directional control valve with dual-coil latching design for stable position retention. Features anti-vibration structure with stainless steel plunger guide, optimized for high-cycle automation systems. Requires 5μm filtered air (ISO 8573-1 class 4) with lubrication not exceeding ISO VG32.
- Robotic arm end-effector control systems
- Plastic injection molding machine clamp units
- Semiconductor wafer handling equipment
- Automotive assembly line fixture controls
- Food packaging machine pneumatic circuits
Installation guidelines:
Mount with M5 screws (recommended torque 1.2N·m). Maintain 15mm clearance
below valve for exhaust flow. Use shock-absorbing brackets in high-vibration
environments. Manual override requires 3mm hex key (included).
| Property | Property Value |
|---|---|
| sku | 2ST03008FI |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC12V |
