Airtac 2ST Fluid Control Valve 2ST05010BI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05010BI Fluid Control Valve Technical Details
- Model: 2ST05010BI
- Type: 5-port 2-position (5/2-way) solenoid valve
- Port configuration: G1/8 (ISO228-1 standard)
- Operating pressure range: 0.2–0.8 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Manual override: Built-in emergency operation button
- Flow capacity: 850 l/min (ANR) at 0.5 MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (Nitrile) compound
- Ambient temperature range: -20℃ to 80℃
- Weight: 650g ±5% (with connectors)
- Dimensions: 80mm(L) × 50mm(W) × 40mm(H)
- Electrical protection: Class F insulation, surge suppression circuit
- Protection rating: IP67 (dust/water resistant)
- Service life: ≥10 million cycles (at rated conditions)
High-speed bistable valve featuring low power consumption (1.6W nominal) and latching coil design for continuous operation. The dual-coil configuration maintains position during power loss, with reinforced brass body for chemical resistance. Requires ISO 8573-1:2010 Class 3.4.2 compressed air quality.
- Automated assembly line clamping systems
- High-cycle packaging machinery actuators
- Medical device sterilization equipment
- Semiconductor wafer handling robots
- Textile machine pneumatic logic control
Installation guidelines:1. Mount with M4 screws using vibration-damping washers
2. Maintain 15mm clearance for heat dissipation
3. Use 60-70% of max flow rate for optimal service life
4. Install downstream filter (5μm) when used with lubricated air
| Property | Property Value |
|---|---|
| sku | 2ST05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | DC24V |
