Airtac 2ST Fluid Control Valve 2ST05010F
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05010F Fluid Control Valve Technical Details
- Model: 2ST05010F
- Type: 5-port 3-position closed center (Pilot-operated)
- Port configuration: 5/3-way closed center
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.7 MPa
- Max flow capacity: 750 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 1.2 kg ±5%
- Dimensions: 132mm(L) × 54mm(W) × 88mm(H)
- Seal materials: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature tolerance: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤50ms (both energize/de-energize)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with closed-center spool design, optimized for precision fluid power systems requiring mid-stroke position holding. Features dual-pressure balanced spool structure and copper-free aluminum alloy body meeting RoHS3 compliance. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Bottle filling station pneumatic circuits
- Textile machinery tension control systems
- Semiconductor wafer handling robots
Installation protocol:
Mount on ISO 5599/1 standard manifold using M5 mounting screws (2.5Nm torque limit).
Maintain 20mm clearance below valve for condensate drainage. Lubricate seals with ISO VG32 turbine oil
during maintenance. Avoid axial piping stress during plumbing installation.
