Airtac 2ST Fluid Control Valve 2ST05015B
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05015B Fluid Control Valve Technical Specifications
- Model: 2ST05015B
- Type: 5/2-way solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil power: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Flow coefficient (Cv): 2.2
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Protection class: IP67 (coil), IP40 (valve body)
- Weight: 0.82 kg (1.81 lbs)
- Dimensions: 120mm(L) × 45mm(W) × 55mm(H)
- Port thread depth: 12mm (minimum engagement)
- Max operating cycles: 10 million (with clean air)
High-flow directional control valve with dual solenoid operation, featuring brass body construction with hard-anodized aluminum sleeve. Designed for precision bi-directional actuator control in industrial automation systems. Includes manual override button for system debugging and emergency operation. Requires ISO 8573-1 class 3 compressed air (max 50μm particle size).
- Pneumatic cylinder sequencing in packaging lines
- Clamping fixture control in CNC machining centers
- Material handling systems with double-acting cylinders
- Automotive assembly line tooling
- Industrial robot end-effector control
Installation guidelines:
Mount horizontally with coil upright. Maintain minimum 20mm clearance around valve for heat dissipation.
Use flexible tubing to prevent mechanical stress. Lubricate with ISO VG32 turbine oil if air lubrication system not present.
| Property | Property Value |
|---|---|
| sku | 2ST05015B |
| Port Size | PT 1/2 |
| Flow Aperture | <10mm> |
| Coil Voltage | DC24V |
