Airtac 2SX Fluid Control Valve 2SX05010C
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05010C Fluid Control Valve Specifications
- Model: 2SX05010C
- Type: 2-position, 5-port direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: ~320g (including coil)
- Dimensions: 62mm(L) × 30mm(W) × 45mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -10℃ to 60℃ (non-freezing environment)
- Flow capacity: 750 l/min (ANR at 0.5 MPa)
- Response time: ≤15ms (at rated voltage)
- Protection rating: IP67 (dust-tight and temporary immersion protection)
High-flow proportional control valve with dual-pressure operation capability, featuring brass main body with electroless nickel plating for corrosion resistance. Designed for precision directional control in pneumatic systems, with integrated LED status indicator and surge protection circuitry. Requires ISO 8573-1:2010 Class 3.4.3 compressed air quality.
- Packaging machinery sequencing systems
- Automated assembly line actuators
- Pneumatic clamping devices in CNC operations
- Food processing equipment (compatible with food-grade lubricants)
- Cleanroom automation in semiconductor manufacturing
Installation note:
Optimal performance achieved when mounted horizontally. Use shock-absorbing
brackets in high-vibration environments. Maintain 15mm minimum clearance
around exhaust ports for proper ventilation.
| Property | Property Value |
|---|---|
| sku | 2SX05010C |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
