Airtac 2SX Fluid Control Valve 2SX05010E
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05010E Fluid Control Valve Technical Details
- Model: 2SX05010E
- Type: 5-port 3-position closed center (Pilot-operated)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: 210g ±5% (including coil)
- Dimensions: 55mm(L) × 35mm(W) × 70mm(H)
- Flow capacity: 750 l/min (ANR) at 0.5 MPa
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Power consumption: ≤1.5W (DC), ≤3.5VA (AC)
- Response time: ≤15ms (exhaust to center position)
- Protection rating: IP67 (dustproof & temporary immersion resistant)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with closed-center configuration, engineered for precision mid-stroke positioning in pneumatic systems. Features dual-pressure operation capability and surge-protected coils. The aluminum alloy body with hard anodizing ensures corrosion resistance in humid environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.4 air quality.
- Robotic gripper pressure balancing systems
- Plastic injection molding machine clamp control
- CNC tool changer positioning mechanisms
- Pharmaceutical blister packaging air circuits
- Lithium battery production line pressure sequencing
Installation protocol:
Mount with vibration-damping gaskets in high-shock environments.
Maintain 15° maximum deviation from vertical axis during installation.
Perform manual override test before power activation.
| Property | Property Value |
|---|---|
| sku | 2SX05010E |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
