Airtac 2SX Fluid Control Valve 2SX05015B
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX Series Fluid Control Valve 2SX05015B Technical Details
- Model: 2SX05015B
- Type: 5-port 3-position closed center (pneumatic pilot operated)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Max flow rate: 1,200 NL/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.8W (standard), 2.2W (high-power variant)
- Weight: 385g ±5g (including coil)
- Dimensions: 64mm(L) × 42mm(W) × 95mm(H)
- Body material: Aluminum alloy (anodized surface)
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with closed-center configuration, engineered for precision directional control in pneumatic circuits. Features dual-pressure operation capability and shock-resistant design with integrated silencer pads. The optimized spool structure reduces internal leakage to ≤5 cm³/min (at 0.5MPa). Requires 5μm filtered compressed air with oil mist lubrication recommended.
- Multi-axis pneumatic actuator synchronization
- Plastic injection molding machine clamp control
- Automated production line indexing systems
- Beverage filling equipment pressure regulation
- Robotic end-effector tool changers
Installation guidelines:
Mount horizontally with manifold brackets (M4×12 screws). Maintain minimum 15mm clearance below exhaust ports for airflow.
Use locknuts with 1.2-1.5Nm torque. Lubricate seals with ISO VG32-grade pneumatic oil during maintenance.
Critical note:
Avoid rapid pressure fluctuations above 0.8MPa/sec. Install pressure regulators upstream for systems with
variable compressor outputs. Not suitable for vacuum applications.
| Property | Property Value |
|---|---|
| sku | 2SX05015B |
| Port Size | PT 1/2 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
