Airtac 2SX Fluid Control Valve 2SX05015C
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05015C Fluid Control Valve Technical Details
- Model: 2SX05015C
- Type: 5/2-way single solenoid operated (monostable)
- Port configuration: 5 ports (P, A, B, EA, EB) / 2 positions
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Flow coefficient (Cv): 1.3
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Medium temperature: 0-60℃
- Seal material: Heat-resistant NBR (Nitrile)
- Body material: Reinforced PBT resin
- Protection rating: IP67 (coil protection)
- Weight: 0.52 kg ±3%
- Dimensions: 58mm(L) × 34mm(W) × 78mm(H) (excluding connectors)
- Mounting orientation: Any (omnidirectional installation)
- Port thread depth: 12mm (minimum engagement)
High-speed 5/2 pneumatic directional valve with low power consumption design (2.5W typical). Features dust-tight metal plunger construction and surge-protected coil. The transparent LED status indicator enables visual operation confirmation. Compatible with ISO 15407-1 standards for pneumatic valve mounting interfaces.
- Double-acting cylinder control in automated assembly lines
- Pneumatic clamping systems in CNC machinery
- Material handling equipment sequencing
- Textile machinery tension control
- Automotive paint shop actuators
- Food processing packaging systems (oil-resistant version available)
Installation guidelines:
Use M5 mounting screws with 0.49-0.59N·m torque. Maintain minimum 30mm
clearance above exhaust ports. For horizontal mounting, install exhaust
silencers downward at 15° angle to prevent debris ingress. Lubricate with
ISO VG32 turbine oil if using non-lubricated air systems.
| Property | Property Value |
|---|---|
| sku | 2SX05015C |
| Port Size | PT 1/2 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
