Airtac 2V Fluid Control Valve 2V250-20-A
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V250-20-A Fluid Control Valve Technical Details
- Model: 2V250-20-A
- Type: 5/2-way double solenoid (bi-stable)
- Port size: G1/4 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage options: DC24V (±10%), AC220V (±10% 50/60Hz)
- Weight: 1.2kg (with connectors)
- Dimensions: 125mm(L) × 55mm(W) × 85mm(H)
- Flow capacity: 1800 NL/min (Cv=2.4)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤25ms (at rated voltage)
- Power consumption: 4.5W (DC24V), 5.5VA (AC220V)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with dual coil latching mechanism, engineered for heavy-duty pneumatic systems requiring position memory. Features brass alloy body with hard-anodized aluminum solenoid housing, optimized for rapid cycling (up to 5Hz). Requires 5μm filtered air with ISO VG32 turbine oil mist lubrication (optional).
- Automated production line clamping systems
- Plastic injection molding machine actuators
- CNC machine tool pneumatic tool changers
- Automotive brake testing equipment
- Foundry air cylinder sequencing
Installation guidelines:
Mount horizontally with coil axis vertical (±30° tolerance).
Use flexible tubing connections to prevent vibration transfer.
Minimum 100mm clearance above valve for heat dissipation.
Apply thread sealant on male ports (PTFE tape prohibited).
- Pre-charge system to 0.3MPa before initial activation
- Install moisture separator upstream (mandatory in humid environments)
- Verify voltage stability within ±10% during cycling
- Replace seals every 5 million cycles (NBR) or 8 million cycles (optional FKM)
| Property | Property Value |
|---|---|
| sku | 2V250-20-A |
| Port Size | BSPT 3/4 |
| Flow Aperture | <25 mm> |
| Coil Voltage | AC220V |
