Airtac 2V Fluid Control Valve 2V250-25-A
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V250-25-A Fluid Control Valve Technical Details
- Model: 2V250-25-A
- Type: 5/2-way double solenoid pilot-operated valve
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.2–0.8 MPa (29–116 PSI)
- Max flow capacity: 2500 L/min (ANR)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 138mm(L) × 45mm(W) × 65mm(H)
- Seal materials: NBR standard (FKM/Viton optional)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Response time: ≤30ms (at rated voltage)
- Port thread depth: 12mm (minimum engagement)
- Protection rating: IP67 (dust/water resistant)
- Service life: ≥10 million cycles (under normal conditions)
High-flow directional control valve with dual coil redundancy, featuring brass body construction with hard anodized aluminum solenoid housing. Designed for heavy-duty pneumatic systems requiring precise bi-directional cylinder control. Includes manual override and surge suppression circuitry. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Automated production line actuator control
- Pneumatic press machine sequencing
- Material handling systems (conveyor diverters/lifters)
- Automotive assembly line tooling
- Plastic injection molding machine controls
- Packaging machinery clamp circuits
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use flexible tubing near ports to reduce vibration stress.
Maintain 20mm clearance on sides for heat dissipation.
Lubricate with ISO VG32 turbine oil if air line lubrication is absent.
| Property | Property Value |
|---|---|
| sku | 2V250-25-A |
| Port Size | PT 1/8 |
| Flow Aperture | <25 mm> |
| Coil Voltage | AC220V |
