Airtac 2WH High-Pressure Solenoid Valve 2WH030-08-B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH High Pressure Solenoid Valve 2WH030-08-B Technical Details
- Model: 2WH030-08-B
- Type: 5/3-way (3-position) closed center, double solenoid operated
- Port size: G3/8 (BSPP thread)
- Operating pressure range: 0.5–25 MPa (72.5–3,625 PSI)
- Maximum pressure: 31.5 MPa (4,565 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil power: 22W (AC), 26W (DC)
- Weight: 2.8 kg (6.17 lbs)
- Dimensions: 145mm(L) × 72mm(W) × 123mm(H)
- Seal materials: HNBR (Hydrogenated Nitrile) + FKM (Fluorocarbon)
- Temperature range: -20℃ to 80℃ (with silicone grease lubrication up to 120℃)
- Response time: ≤50ms (excitation), ≤70ms (de-excitation)
- Protection rating: IP67 (coil), IP65 (valve body)
- Flow capacity: 1,200 Nl/min (Cv=2.0) at 0.7MPa
- Port configuration: 5 ports (P, A, B, R, S) + 2 exhausts
Heavy-duty high-pressure solenoid valve engineered for industrial hydraulic systems requiring precise directional control under extreme pressures. Features dual manual override buttons, shock-resistant brass body with nickel plating, and hardened stainless steel spool. Includes LED status indicator and surge protection circuitry. Requires ISO 4401 mounting interface.
- Hydraulic press clamping/unclamping sequence control
- High-pressure lubrication systems in steel mills
- Construction machinery boom cylinder control
- Automotive brake testing equipment
- Plastic injection molding machine hydraulics
- Ship steering gear hydraulic power units
Installation requirements:
Mount horizontally with vibration isolators. Maintain oil cleanliness of NAS 9 class (ISO 4406 16/14/11)
using 10μm filtration. Allow 150mm clearance above valve for maintenance access.
Perform manual cycling weekly if used intermittently.
| Property | Property Value |
|---|---|
| sku | 2WH030-08-B |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
