Airtac 2WL High Pressure Solenoid Valve 2WL03006B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL03006B High-Pressure Solenoid Valve Specifications
- Model: 2WL03006B
- Type: 2-position, 3-way direct-acting (normally closed)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.5–20 MPa (7–2900 PSI)
- Max pressure capacity: 25 MPa (burst pressure 40 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Coil insulation class: F (155℃)
- Power consumption: 4.8W (DC), 5.5VA (AC)
- Flow coefficient (Cv): 0.15 at 7 bar
- Response time: ≤15ms (excitation), ≤20ms (de-energization)
- Seal material: Fluorocarbon rubber (FKM) + NBR compound
- Body material: Anodized aluminum alloy (ADC12)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Medium temperature: ≤70℃ (continuous)
- Protection rating: IP67 (dustproof & temporary immersion)
- Weight: 480g ±5% (including coil)
- Dimensions: 64mm(L) × 48mm(W) × 88mm(H)
- Mounting orientation: Any (horizontal recommended for max lifespan)
Heavy-duty high-pressure solenoid valve engineered for industrial hydraulic and pneumatic systems requiring extreme pressure stability. Features dual-seal structure with hardened stainless steel plunger for 500,000+ cycle durability. Includes manual override button for system debugging. Compatible with ISO VG32 hydraulic oil and most non-corrosive gases.
- Hydraulic pressurization systems in die-casting machines
- High-pressure gas charging stations (CNG/LPG)
- Industrial cleaning equipment (200+ bar water jet systems)
- Test bench pressure control for automotive components
- Mining hydraulic support systems
Critical notes:
Requires 10μm filtration for media. Install pressure relief valve downstream.
For continuous operation above 15MPa, add heat sink (recommended air flow ≥0.3m/s).
Maximum 85% duty cycle at peak pressure.
- Flush pipeline before installation (≥15L/min for 5 mins)
- Use torque wrench for port connections (15-20N·m for G1/8)
- Maintain ≥30mm clearance from vibrating components
- Ground coil terminal to prevent EMI interference
| Property | Property Value |
|---|---|
| sku | 2WL03006B |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
