Airtac 2WL High Pressure Solenoid Valve 2WL03008EI
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03008EI Technical Details
- Model: 2WL03008EI
- Type: 3-position, 5-way direct-acting (high pressure series)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.5–16 MPa (7–2320 PSI)
- Maximum pressure: 21 MPa (3045 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Coil insulation class: Class F (155°C)
- Weight: 450g ±5% (including coil)
- Dimensions: 72mm(L) × 54mm(W) × 95mm(H)
- Seal materials: FKM (fluorocarbon rubber) standard, EPDM optional
- Temperature range: -10℃ to 150℃ (with FKM seals)
- Power consumption: ≤3.5W (DC), ≤5.5VA (AC)
- Response time: ≤15ms (at 20℃, 1MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Flow coefficient (Cv): 2.5 (at 7 bar)
Industrial-grade high-pressure solenoid valve featuring triple-position control (mid-position exhaust) and hardened stainless steel plunger system. Engineered for hydraulic/pneumatic hybrid systems requiring extreme pressure stability. Incorporates shock-resistant coil encapsulation and anti-vibration spool design. Requires 10μm filtration with oil mist lubrication (ISO VG32 recommended).
- Hydraulic press clutch/brake control systems
- CNC machine tool hydraulic power units
- High-pressure water jet cutting equipment
- Off-road vehicle pneumatic suspension systems
- Industrial boiler safety venting mechanisms
- Pressure testing rigs for aerospace components
Installation protocol:
Mount horizontally with 15mm clearance below for exhaust port maintenance.
Use torque-limited wrench (15-20Nm for body bolts, 8-10Nm for port fittings).
Perform initial 500-cycle dry run before pressure loading.
- Lubrication interval: 1 million cycles or 12 months
- Diaphragm replacement: 5 million cycles
- Coil lifespan: 10 million cycles @ 25℃ ambient
| Property | Property Value |
|---|---|
| sku | 2WL03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
