Airtac 2WL High Pressure Solenoid Valve 2WL05010-X0
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL05010-X0 High Pressure Solenoid Valve Technical Details
- Full model number: 2WL05010-X0 (base model) with optional suffixes
- Valve type: 5-port 2-position (5/2-way) pilot-operated
- Port thread: G1/8 (ISO228 standard) with NPT optional
- Max working pressure: 25 bar (362.5 PSI) - 3× standard valve capacity
- Voltage variants: DC12V(±10%), DC24V(±10%), AC110V(±10% 50/60Hz), AC220V(±10% 50/60Hz)
- Cv value: 1.6 (Kv=1.84 m³/h) at 6 bar
- Weight: 780g ±5% (excluding connectors)
- Body dimensions: 125mm(L) × 50mm(W) × 60mm(H) (manifold mounting surface)
- Seal materials: HNBR main seals with FKM backup rings
- Fluid temperature: -10℃ to 80℃ (with dry air), 0-60℃ (with lubricated air)
- Coil insulation: Class F (155℃) with thermal overload protection
- Response time: ≤15ms (energize), ≤20ms (de-energize) at rated voltage
- Protection grade: IP67 (coil) / IP40 (valve body)
- Endurance: 50 million cycles minimum (IEC 60534 standard)
Industrial-grade high-pressure solenoid valve engineered for heavy-duty pneumatic systems. Features triple-layer chrome-plated spool for reduced friction and diamond-coated orifice seats for zero-leakage performance. The dual-coil heat dissipation design allows 100% ED (continuous duty) operation. Compatible with ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Hydraulic pump control in injection molding machines (clamping units)
- High-speed cylinder sequencing for stamping presses
- Compressed air distribution in CNC tool changers
- Dust collector pulse-jet valve systems
- Test bench pressure regulation (automotive brake systems)
Critical installation parameters:1. Must install downstream moisture separator (40μm filter + auto-drain)
2. Minimum 2D straight pipe requirement at outlet port
3. Horizontal mounting preferred - vertical allowed with ±15° tolerance
4. Silicone-free grease required for threaded connections
Seal replacement interval: 2 years (normal use) / 1 year (high humidity environments)
| Property | Property Value |
|---|---|
| sku | 2WL05010-X0 |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | DC24V |
