Airtac 2WL High Pressure Solenoid Valve 2WL05010EI
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL05010EI High-Pressure Solenoid Valve Specifications
- Model: 2WL05010EI
- Type: 2-position, 5-port direct-acting (monostable)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.5–21 MPa (72.5–3045 PSI)
- Maximum working pressure: 25 MPa (3626 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 520g ±5% (including coil)
- Dimensions: 68mm(L) × 54mm(W) × 80mm(H) (body only)
- Port-to-port length: 34mm (between G1/8 ports)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE backup rings
- Temperature range: -20℃ to 150℃ (with intermittent peak tolerance to 180℃)
- Power consumption: 3.5W (DC24V), 4.2VA (AC220V)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection rating: IP67 (coil), IP65 (valve body)
- Fluid compatibility: ISO VG32/46 hydraulic oil, air (dew point -20℃)
- Cycle life: ≥5 million cycles (at rated pressure)
High-performance hydraulic/pneumatic directional control valve featuring military-grade sealing technology. The forged aluminum alloy body withstands extreme pressure surges, with shock-resistant coil design for vibration-intensive environments. Requires 10μm filtration (βₙ≥75) and periodic lubrication every 2,000 operating hours.
- Hydraulic press clamping/unclamping systems
- High-pressure pneumatic test benches (leak detection systems)
- Injection molding machine core-pull mechanisms
- Construction equipment hydraulic controls (excavators, compactors)
- CNC machine tool hydraulic indexing tables
- Offshore platform emergency shut-off systems
Installation protocol:
Mount horizontally with fluid flow arrow aligned. Use anti-vibration mounts in mobile applications.
Perform pressure decay test (0.5MPa/min max) after installation. Replace O-rings every 10,000 cycles
under continuous high-pressure operation.
| Property | Property Value |
|---|---|
| sku | 2WL05010EI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC24V |
