Airtac 2WT Extra High Flow Solenoid Valve 2WT03006FI
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT03006FI High Flow Solenoid Valve Specifications
- Model: 2WT03006FI
- Type: 5/2-way direct-acting with pilot assist (double solenoid)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 2200 NL/min (Cv=2.3 at 0.5 MPa)
- Response time: ≤30ms (open), ≤45ms (close)
- Seal material: HNBR rubber (oil & heat resistant)
- Temperature range: -5℃ to 70℃ (fluid/ambient)
- Power consumption: ≤3.5W (AC), ≤4.2W (DC)
- Port thread depth: 13mm (minimum engagement)
- Protection rating: IP67 (dust/water resistant)
- Weight: 650g ±5% (with connectors)
- Dimensions: 85mm(L) × 56mm(W) × 90mm(H)
Industrial-grade high flow solenoid valve designed for heavy-duty pneumatic systems requiring rapid cycling. Features dual-coil latching design for energy efficiency and fail-safe position memory. The reinforced aluminum alloy body withstands vibration up to 10Hz/2mm amplitude. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) for optimal performance.
- Automated production line clamping systems
- Automotive tire assembly machinery
- High-speed packaging equipment actuators
- Injection molding machine ejectors
- Foundry air cylinder controls
Installation protocol:
Mount in vibration-damped orientation (vertical preferred). Maintain minimum
15mm clearance on all sides for heat dissipation. Use copper-free anti-seize
compound on port threads. Test with 80% rated voltage during commissioning.
| Property | Property Value |
|---|---|
| sku | 2WT03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC12V |
