Airtac 2WX Fluid Solenoid Valve 2WX03006CI
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX03006CI Fluid Solenoid Valve Specifications
- Model: 2WX03006CI
- Type: 5/2-way double solenoid (balanced piston design)
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Max flow rate: 750 l/min (Cv=1.2)
- Response time: ≤15ms (at 0.5 MPa)
- Weight: 220g ±5% (without coil)
- Dimensions: 58mm(L) × 34mm(W) × 76mm(H)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (hydrogenated nitrile) for high temp resistance
- Temperature range: -10℃ to 120℃ (non-freezing conditions)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
- Cycle life: ≥10 million operations
High-speed 5-port directional valve with dual manual override, featuring pressure-balanced spool design for consistent performance under fluctuating line pressures. The hardened aluminum construction with triple-layer chrome plating ensures corrosion resistance in humid environments. Includes LED status indicator and surge protection circuit.
- Automated assembly line cylinder control
- Textile machinery pneumatic circuits
- Plastic injection molding ejector systems
- Food processing equipment (oil/fat-resistant version available)
- Robotic gripper position switching
Installation guidelines:1. Mount in vibration-free location using M4 mounting screws (max torque 1.2N·m)
2. Maintain 20mm clearance around exhaust ports for airflow
3. Use ISO 8573-1 Class 3 compressed air (max particle size 5μm)
4. For horizontal mounting, install drip leg before valve inlet
5. Pipe connections should follow torque specs: 12-15N·m for NPT, 8-10N·m for BSPP
| Property | Property Value |
|---|---|
| sku | 2WX03006CI |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | AC 110V |
