Airtac 2WX Fluid Solenoid Valve 2WX05010FI
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05010FI Fluid Solenoid Valve Technical Details
- Model: 2WX05010FI
- Type: 2-position 5-way (monostable)
- Port configuration: 1/4" BSPP (G1/4)
- Operating pressure range: 0.05–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Fluid compatibility: Compressed air (max 50μm filtered), inert gases, water (distilled)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Seal materials: HNBR main seals with FKM backup rings
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Flow capacity: 850 l/min (Cv=1.2)
- Protection class: IP67 (coil)/IP40 (valve body)
- Weight: 320g ±5% (with connector)
- Dimensions: 58mm(L) × 42mm(W) × 52mm(H) (excluding ports)
High-flow directional control valve with copper-free aluminum alloy body, featuring integrated manual override and surge protection circuitry. The optimized spool design reduces hysteresis while maintaining 10 million cycle durability. Requires 5-60μm filtration for optimal performance.
- Automated bottle filling/capping systems
- Textile machinery cylinder sequencing
- Food-grade pneumatic conveying controls
- Semiconductor wafer handling robots
- Mobile hydraulic pilot stage switching
Installation protocol:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2Nm).
Maintain 15° maximum angular deviation from vertical axis. Pipe joint tightening torque: 12-15Nm.
| Property | Property Value |
|---|---|
| sku | 2WX05010FI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
