Airtac 300M Solenoid Valve Manifold 300M-8F
Genuine AirTAC valve manifold, order code 300M-8F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold300M (for 4A300)
- Stations8 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 300M Solenoid Valve Manifold 300M-8F
Eight 4A300 air-piloted valves run from one 3/8 inch supply port on the AirTAC 300M-8F, the eight-station PT-threaded version of the 300M bank. A common supply and common exhaust replace eight separate inlet and outlet connections, keeping the valve assembly compact on the machine frame.
The catalog length formula gives 52 mm for the first station plus 28 mm per additional station, so eight stations occupy 248 mm of mounting length. The package contains the manifold together with its seals and screws, operates on air filtered to 40 um and tolerates -20 to +70 C.
Airtac 300M Solenoid Valve Manifold 300M-8F Technical Specifications
| Order code | 300M-8F |
|---|---|
| Product | Valve Manifold |
| Manifold | 300M (for 4A300) |
| Stations | 8 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
Eight stations is exactly where the 400M series ends: if your valves are 4A400, move to a 400M manifold with its 1/2 inch supply port, but for 4A300 valves this 300M-8F is the correct match and still leaves room to grow toward the 12-station maximum. Within 300M, step down to 300M-7F for seven valves or up to 300M-9F for nine, closing any gap with the P-300M-R2 blank plate kit.
Applications
Palletizer and case-packer clamp banks
Supply the 4A300 valves behind eight gripper or clamp cylinders from one 248 mm PT-threaded valve bank.
Conveyor lift, gate and reject stations
Mount lift, gate and reject valves side by side, all fed by the single 3/8 inch supply port of the 300M-8F.
Modular machine fixture control
Consolidate eight actuator circuits in one bank so adding circuits later only means extending toward 12 stations.
FAQ
What are the key figures of the AirTAC 300M-8F?
It is a 300M manifold for 4A300 valves with 8 stations and PT threads, a 3/8 inch supply port P, and a length A of 248 mm (52 mm base plus 28 mm per extra station). The series maximum is 12 stations, fluid is air filtered to 40 um, and the temperature range is -20 to +70 C.
Can I extend the bank beyond eight valves later?
Yes. The 300M family accepts up to 12 stations, so future growth goes to 300M-9F and beyond; until then, keep the code exactly as needed or close spare positions with the separately ordered P-300M-R2 blank plate kit.
