Airtac 3A100 Pneumatic Control Valve 3A11006NO
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Double pneumatic pilot control features inherent memory function;
3. Precision-engineered internal bore minimizes friction resistance, enabling low actuation pressure and extended service life;
4. Maintenance-free operation without lubrication required;
5. Supports versatile mounting orientations for simplified installation and operation;
6. Compatible with modular valve base integration to optimize space utilization.
Category: Pneumatic Pilot Valves, Brand: AirTAC, Series: 3A100
AirTAC 3A100 Series 3A11006NO Pneumatic Control Valve Technical Details
- Full model designation: 3A11006NO (3A100 series)
- Valve type: 3/2-way normally open (direct acting)
- Port configuration: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 750 L/min (ANR)
- Actuation method: Pneumatic pilot control
- Response time: ≤30ms (at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature tolerance: -10℃ to 120℃ (with dry air)
- Body material: Anodized aluminum alloy
- Port thread depth: 12mm (minimum engagement)
- Weight: 320g ±5g
- Dimensions: 56mm(W) × 38mm(H) × 72mm(D)
- Vibration resistance: ≤55Hz with 1.5mm amplitude
- Shock resistance: 100m/s² (3 axes)
- Mounting orientation: Any (horizontal preferred for maintenance)
High-flow pneumatic valve with rapid response characteristics, featuring wear-resistant internal guides and dual-chamber sealing technology. The hardened aluminum body withstands industrial vibration environments, while the enlarged exhaust port (φ3.5mm) ensures quick pressure release. Compatible with ISO 15407-1 standards.
- Pneumatic pressurization systems in automotive assembly lines
- High-cycle molding machine ejector controls
- Bottle blowing machine air distribution
- Textile machinery tension control systems
- Food processing vacuum/pressure switching units
Maintenance protocol:
Lubricate pilot piston every 2 million cycles using ISO VG32 turbine oil.
Install downstream filters (5μm) when used with non-lubricated air systems.
| Property | Property Value |
|---|---|
| sku | 3A11006NO |
| Position | 3-Port 2-Position |
| Initial Position | Normally Open |
| Port Size | PT1/8 |
