Airtac 3A100 Pneumatic Control Valve 3A120-06
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Double pneumatic pilot control features inherent memory function;
3. Precision-engineered internal bore minimizes friction resistance, enabling low actuation pressure and extended service life;
4. Maintenance-free operation without lubrication required;
5. Supports versatile mounting orientations for simplified installation and operation;
6. Compatible with modular valve base integration to optimize space utilization.
Category: Pneumatic Pilot Valves, Brand: AirTAC, Series: 3A100
AirTAC 3A120-06 Pneumatic Control Valve Technical Details
- Model: 3A120-06 (Series 3A100)
- Valve type: 3-position, 5-way closed center
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Control method: Air pilot operated (single/double control)
- Max flow rate: 850 L/min (ANR)
- Response time: ≤0.1 sec (at 0.5 MPa)
- Weight: 280g ±5% (without fittings)
- Dimensions: 58mm(W) × 45mm(H) × 105mm(L)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Port thread depth: 12mm (minimum engagement)
- Housing material: Reinforced PBT with glass fiber
- Manual override: Optional paddle-type actuator
High-flow directional control valve with center-block function, featuring dual-pressure operation capability. The optimized spool structure reduces air consumption by 15% compared to previous generation models. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Clamping mechanisms in CNC machining centers
- Rotary indexing tables with pneumatic braking
- Material handling systems requiring mid-position lock
- Plastic injection molding machine ejectors
- Automated assembly line tool changers
Installation guidelines:
Mount with vibration-damping brackets in high-cycle applications (>5Hz).
Maintain 1.5x port diameter clearance between valve and adjacent components.
Lubricate with ISO VG32 turbine oil if using non-lubricated air.
| Property | Property Value |
|---|---|
| sku | 3A120-06 |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Port Size | PT1/8 |
