Airtac 3A200 Pneumatic Control Valve 3A220-08
2. Double pneumatic pilot design with memory function;
3. Precision-machined internal bores with special surface treatment deliver low friction resistance, minimal actuation pressure, and extended service life;
4. Oil-free lubrication system requiring no maintenance;
5. Multi-position mounting capability for flexible installation and operation;
6. Compatible with base manifold valve blocks to optimize space utilization.
Category: Pneumatic Control Valves, Brand: AirTAC, Series: 3A200
AirTAC 3A220-08 Pneumatic Control Valve Specifications
- Model: 3A220-08 (3A200 series)
- Type: 5/2-way monostable (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.8 MPa
- Max flow capacity: 850 L/min (ANR)
- Actuation type: Pneumatic pilot control
- Voltage options: DC12V/24V, AC110V/220V (for solenoid pilot version)
- Weight: 480g ±2%
- Dimensions: 58mm(L) × 45mm(W) × 98mm(H)
- Valve body material: Anodized aluminum alloy
- Seal material: NBR/FKM optional
- Temperature range: -5℃ to 80℃ (NBR), -10℃ to 150℃ (FKM)
- Response time: ≤50ms (at 0.5MPa)
- Protection rating: IP67 (solenoid version)
- Mounting style: Sub-base or side bracket
High-flow directional control valve with modular design, featuring wear-resistant spool structure and dual-position memory function. The 3A220-08's large exhaust ports (M5x0.8) ensure rapid cylinder movement, while its anti-vibration design maintains stable operation in mobile machinery. Requires 5μm filtered compressed air with lubrication (ISO 8573-1 class 4).
- Automated assembly line cylinder sequencing
- Plastic injection molding machine clamp control
- Textile machinery pneumatic circuits
- Automotive welding fixture positioning
- Bottle filling station actuator control
Installation note:
For optimal performance, maintain ambient temperature below 60℃ and install shock absorbers when used in high-vibration environments. Lubricate pilot air with ISO VG32 turbine oil (1-2 drops/m³ air).
| Property | Property Value |
|---|---|
| sku | 3A220-08 |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Port Size | PT1/4 |
