Airtac 3L 2-Position 3-Way Pull-Type Manual Valve 3L210-06
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Spool-type structure provides excellent sealing performance, compact size, lightweight construction, and tool-free assembly/disassembly;
3. Specially machined internal bore minimizes friction resistance while extending operational lifespan;
4. Lubrication-free maintenance;
5. Multiple mounting orientations enable flexible installation configurations;
Category: Manual Pull Valve , Brand: AIRTAC , Series: 3L
AirTAC 3L210-06 3/2-Way Manual Pull Valve Technical Details
- Model: 3L210-06
- Type: 3/2-way manual reset valve (spring return)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 750 L/min (Cv=1.2)
- Valve body material: Anodized aluminum alloy
- Seal material: High-grade NBR (Nitrile rubber)
- Operating temperature: -5℃ to 80℃ (fluid), -20℃ to 60℃ (ambient)
- Actuation force: ≤15N manual pull force
- Reset time: ≤0.5s (spring return)
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 72mm(H)
- Port thread depth: 10mm engagement length
- Leakage rate: <5 bubbles/min (ISO 6952 standard)
Robust manual override valve with tactile position feedback, featuring dual-color position indicator (red/green collar). Designed for systems requiring manual intervention without electrical power. The ergonomic pull knob includes anti-slip grooves and over-force protection. Compatible with ISO 15407-1 standards.
- Emergency stop/start functions in conveyor systems
- Production line manual override stations
- Pneumatic system maintenance bypass
- Training simulators for industrial controls
- Safety interlocks in press machinery
Operation guidance:
Pull straight outward until audible click confirms position change.
For continuous manual operation, rotate knob 90° to lock in activated state.
Lubricate sliding surfaces with ISO VG32 hydraulic oil annually.
| Property | Property Value |
|---|---|
| sku | 3L210-06 |
| Position | 3-Port 2-Position |
| Port | PT1/8 |
