Airtac 3L 2-Position 3-Way Pull-Type Manual Valve 3L310-10
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Spool-type structure provides excellent sealing performance, compact size, lightweight construction, and tool-free assembly/disassembly;
3. Specially machined internal bore minimizes friction resistance while extending operational lifespan;
4. Lubrication-free maintenance;
5. Multiple mounting orientations enable flexible installation configurations;
Category: Manual Pull Valve , Brand: AIRTAC , Series: 3L
AirTAC 3L310-10 Manual Lever Valve (3/2-Way) Full Specifications
- Model: 3L310-10
- Type: 3/2-way manual lever operated (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.8 MPa
- Flow capacity: 850 L/min (ANR)
- Actuation force: ≤5 N
- Body material: Aluminum alloy (hard anodized)
- Seal material: HNBR (hydrogenated nitrile) for high temperature resistance
- Temperature range: -20℃ to 120℃ (with HNBR seals)
- Weight: 210g ±5g
- Dimensions: 58mm(L) × 42mm(W) × 75mm(H)
- Port thread depth: 12mm
- Operating cycles: ≥500,000 (mechanical life)
- Mounting options: Direct piping or subplate mounting (ISO 15407-1 compatible)
Robust manual override valve with tactile feedback lever, designed for emergency operation or maintenance bypass in pneumatic systems. Features dual-color position indicator (green/red) and anti-vibration lock mechanism. Compatible with ISO 8573-1:2010 Class 3 compressed air quality.
- Production line emergency stop override systems
- Hydraulic/pneumatic system maintenance bypass
- Agricultural equipment manual control stations
- Plastic injection molding machine safety circuits
- Railway braking system test points
Installation best practice:
Install with lever axis perpendicular to piping direction for optimal ergonomics.
Apply thread sealant only on male ports (not NPT threads). Perform monthly lever
stroke checks in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | 3L310-10 |
| Position | 3-Port 2-Position |
| Port | PT3/8 |
